Basic GUI API


Basic GUI Object​

This section includes properties, functions and events for basic GUIs. Examples at Scripting examples

Constructor - new Gui(options?)​

Options:​

billBoardMode Whether the GUI should follow the user or not billBoardMode = 0 -> No billboard effect billBoardMode = 1 -> Follows the user on the X axis (default) billBoardMode = 2 -> Follows the user on the Y axis

eg: new Gui({billBoardMode:0})

Properties​

ID - gui.id​

  • Returns: string, the GUI's unique id.
  • Can be set. eg: feature.id = 'myvoxId'

Uuid - gui.uuid​

  • Returns: string, the GUI's unique uuid.

feature - gui.feature​

  • Returns: Feature, the parent feature

showing - gui.showing​

  • Returns whether the GUI is shoing or not

listOfControls - gui.listOfControls​

  • Returns: an array of guiControls.

defaultControl - gui.defaultControl​

  • Returns an example of default control.

Methods​

addButton(text=null,positionInGrid=[0,0],id=null) - gui.addButton('My button')​

  • Arguments:
    • text (optional): a string,
    • Id (optional): a string,
    • positionInGrid (optional): An array of 2 integers, the first integer being the row number, and the second being the column number.
  • Returns: a guiControl of the button type.

addText(text=null,positionInGrid=[0,0],id=null) - gui.addtext('My text')​

  • Arguments:
    • text (optional): a string,
    • positionInGrid (optional): An array of 2 integers, the first integer being the row number, and the second being the column number.
  • Returns: a guiControl of the text type.

getControlById(id) - gui.getControlById('buttonId')​

  • Arguments: a string
  • Returns: a guiControl or Null

getControlByUuid(id) - gui.getControlByUuid('wdwdw-dwd-wd..')​

  • Arguments: a string
  • Returns: a guiControl or Null

getControlByPosition(array) - gui.getControlByUuid([1,0])​

  • Arguments: an array of 2 integer.
  • Returns: a guiControl or Null

show() - gui.show()​

  • Returns: void

destroy() - gui.destroy()​

  • Returns: void

guiControl Object​

This section includes properties, functions and events for basic GUIs.

Properties​

gui - guiControl.gui​

  • Returns: a FeatureBasicGui object, the parent GUI

id - guiControl.id​

  • Returns: string, the guiControl's id.
  • Can be set. eg: control.id = 'myId'

Uuid - guiControl.uuid​

  • Returns: string, the guiControl's unique uuid.

type - guiControl.type​

  • Returns: string, the type of guiControl At the moment this can only return button or text

text - guiControl.text​

  • Returns: string, the text of the Text or Button control

positionInGrid - guiControl.positionInGrid​

  • Returns: an Array of 2 integers, the position of the control in a grid. Default is [0,0]

summary - guiControl.summary​

  • Returns: an object with the basic information of the control.
  • Useful for console.log in the grid

Methods​

update() - guiControl.update()​

Update the control.

  • Returns void
